Isight Basic Components
Isight Components Available for All Package Levels
Isight Basic Component List and Compatibility Information
The following list outlines components available for all Isight package levels. These products are licensed by Dassault Systèmes Simulia Corp and can only be used or reproduced in accordance with the terms of such license. SIMULIA does not claim ownership of the third-party products that interface with these components. These third-party products are not SIMULIA Programs and are not warranted or supported by SIMULIA, Dassault Systèmes SA, or its subsidiaries.
With the release of Isight/SEE 5.8, Isight runs only on 64-bit platforms. Third-party products for which we create components may still require (or optionally allow) execution on 32-bit platforms. To execute 32-bit third-party programs with Isight/SEE 5.8, users must establish the necessary cross-platform communication environment.
Isight Design Gateway, Runtime Gateway, and Simflow packages
For information about compatibility with specific versions of third-party products, please refer the Isight Program Directory for the particular Isight release.
Exchange Data and Execute Abaqus Solvers or Abaqus/CAE
The Abaqus component allows Isight to exchange data with Abaqus and to control the execution of Abaqus analyses. The component scans either a model database (.cae) file or an input (.inp) file and generates a list of input parameters that Isight can modify. The input parameters can include loads, boundary conditions, and material and section properties as well as sketcher parameters, such as extrusion depth and chamfer radius. The component starts an Abaqus analysis and reads a set of output parameters from the resulting output database (.odb) file or data (.dat) file. Once configured, users can use the Abaqus component with design drivers to perform parameter scans, design of experiments, Monte Carlo simulation, or optimization on Abaqus models.
| Platforms: | Windows/x86-32, Windows/x86-64, Linux/x86-32, Linux/x86-64 Note: Isight 5.9 does not work on 32-bit machines, but older versions of Abaqus do. |
| License: | Token |
Perform Basic Mathematical Calculations With Ease
| Platforms: | All |
| License: | None |
Interact With Microsoft COM Objects
| Platforms: | All |
| License: | None |
Read/Write Data to/from Data Sources and Parameters
| Platforms: | All |
| License: | None |
Attached Files
| Name/Description | Last Updated |
| Simcode-Name-Value-File.avi Simcode component execution of an analysis code with parsing of name-value input and output files |
12/27/2007 5.3 mb |
Exchange Data With Databases
| Platforms: | All |
| License: | None |
Exchange Data With and Execute Dymola
The Dymola component creates a direct link to Dymola, allowing the user to specify analysis input and output parameters and execute Dymola. This component can be used together with Isight design drivers to perform Dymola optimization, DOE, or Monte Carlo simulation.
| Platforms: | Windows/x86-64 Note: Isight requires 64-bit hardware, but Dymola may still run on 32-bit hardware. |
| License: | None |
Additional Materials
| Name/Description | Last Updated |
| Dymola Specification Sheet Specification sheet for the Dymola component. |
1/20/2011 |
| SIMULIA-Isight-Dymola-Video.avi Dymola process integration using the Dymola component. |
8/4/2010 4.9 mb |
Exchange Data With Microsoft Excel
| Platforms: | Windows/x86-64 |
| License: | None |
Grid Plug-in for Use With LSF
| Platforms: | All |
| License: | None |
Grid Plug-in for Use With PBS/Pro, OpenPBS, and TORQUE Grid Software
| Platforms: | All |
| License: | None |
Grid Plug-in for Use With SSH and RSH
| Platforms: | All |
| License: | None |
Execute an Isight Description File
| Platforms: | All |
| License: | None |
Execute Isight FDC Programs in Isight
| Platforms: | All |
| License: | None |
Prepare and Parse ASCII Text Files Using Isight Fast Parser
| Platforms: | All |
| License: | None |
Loop Over Workflow Iterations Based on Specified Criteria: As While, Do Until, for, or for Each
| Platforms: | All |
| License: | None |
Automatically Send Email to One or More Recipients During Execution of a Sim-Flow
| Platforms: | All |
| License: | None |
Compute Output Parameter Noise Level Caused by Input Parameter Scans
| Platforms: | All |
| License: | None |
Executes a Task Swiftly
| Platforms: | All |
| License: | None |
