Architect vs draftsman : a matter of scope
Many people planning on building a house or are interested in construction or design get confused about the differences between an architect and a draftsman. We often see people who use the terms draftsman and architect interchangeably. As both architects and draftsmen are involved in the design process, this is a common mistake to make.
While there are similarities between the two, being an architect and a draftsman are two quite separate disciplines. They both have their own unique set of skills and distinct roles within the industry.
Learn more about those two interrelated professions in this page.
Discover the Dassault Systèmes solutions for CAD drafting
Expert architects and drafters turn to Dassault Systèmes for powerful 2D drafting software and exemplary 3D drafting software. Creating technical drawings is easier and faster with unique solutions such as the standalone program Draftsight Professional and SOLIDWORKS Drafter which is included as part of the SOLIDWORKS Cloud Offer.
SOLIDWORKS Cloud
Get ready for the next generation of design solution, developed by the same team that brought you SOLIDWORKS 3D CAD
3DEXPERIENCE DraftSight Professional
3DEXPERIENCE DraftSight Professional provides architects, engineers, designers, and construction with complete 2D and 3D CAD Drafting solutions. Professionals can create, view, and edit DWG or DXF files easily in either 2D or 3D formats.
The architect, his role and attibutions in an architectural project
From concept to reality: the vital role of architects in construction
The role of an architect is much more involved than the duties of a drafter. Architects devise plans for commercial buildings, offices, houses, factories, and other structures. An architect will come up with the entire concept for a building or structure, including how it will look, how it will function, and how it will sit in relation to its surroundings.
Architects must have a high level of education. At a minimum, an architect must complete an undergraduate university degree. Many architects also go on to attain a master’s degree in architecture. The process of becoming a fully qualified architect can take anywhere from five to seven years or more. Architects that work in the United States must pass the Architect Registration Examination test before they can be licensed. A license to practice architecture must be renewed periodically.
Architects often become senior partners or associates in architectural firms. They can also work as freelance consultants, work as a lead architect in the public sector, or pursue career opportunities in other countries.
The collaboration between architects, engineers, and builders
At the beginning of a building project, the architect will create a detailed design using CAD software. This design is used to provide instructions to builders and engineers on how to construct the building.
An architect typically also uses 3D modeling software to create a realistic render of what the building or structure will look like when it is completed. These renders are used to showcase the concept to clients and can also provide more details for engineers and construction teams than 2D technical drawings can.
Architects often meet with clients, engineers, and builders during every stage of the construction phase. They come up with cost estimates and project timelines and must continuously monitor the progress of the construction project. An architect will also be responsible for making sure the plans comply with zoning laws, building codes, fire codes, accessibility laws, and any other civic regulations.
What makes a good architect?
Architects require exceptional design skills and an artistic outlook. They must have an analytical mind and excellent problem-solving skills. Architects need to pay attention to every detail of a design, so they must be focused and disciplined. As designs often change during the construction process, architects also need to be adaptable and flexible.
