MECAmaster Assembly for V6
MECAmaster Assembly for V6, as MECAmaster Assembly for CATIA V5, is a software dedicated to 3D Tolerance Analysis (and 3D Loads Analysis) helping the...
A solution by: MECA MASTER
Application domain: Mechanical Design
Solution Overview
MECAmaster Assembly for V6, as MECAmaster Assembly for CATIA V5, is a software dedicated to 3D Tolerance Analysis (and 3D Loads Analysis) helping the designers to work on Product and Process optimization from a geometrical point of view from preliminary phases to advanced design phases :
- Is the assembly concept optimal taking account of defined requirements ?
- Is the assembly process well adapted ?
- What is the best specification/tolerance to define on my Part ?
- What will be the consequence on my assembly of a tolerance modification, or a non-conformity ?
- etc.
With MECAmaster, integrated into CATIA, you will have the possibility to simulate the impact of Product and Process tolerances, and the impact of Assembly Concept / Assembly sequences on the 3D geometrical requirement thanks to a powerful 3D Tolerance Stack-Up Analysis.
Benefits
- simulate and compute quickly and easily, in 3D, static loads on an assembly
- simulate and compute quickly and easily, in 3D, tolerances stack-up
- anticipate from preliminary phases the impact of assembly concept / design choices on final geometrical requirements
- reduce costs with a well optimized tolerance definition keeping a full controlled quality on geometrical requirements
- experiment directly in MECAmaster the contribution on final geometrical requirements of specified annotations defined on the CATIA model thanks to 3DMASTER integration
